729106/100MPA

Consultar precio

Hydraulic connection nipple

MPN: 729106/100MPA Marca: SKF Categoría: Productos Industriales SKF Subcategoría: Componentes Industriales SKF Familia: Producto Genérico SKF Subfamilia: Componente Genérico SKF
SKF provides a wide range of connection nipples covering many different thread combinations and sizes. They are used as adapters to enable pipes and hoses to be connected to different thread sizes.
Código UNSPSC 27112908.0
Código eClass 23-05-19-01
Material Chromium molybdenum steel, hardened and tempered
Peso neto del producto 0.12 kg
Color Metálico
Presión máxima 100 MPa
Ancho a través de los planos 32 mm
Connecting cone diameter 8.5 mm
Connecting thread 1 NPT 3/8
Connecting thread 2 G 1/4
Connection type Recto
Length of connecting thread 1 18 mm
Length of connecting thread 2 17 mm
Suitable for use with quick connection nipple No
Total lenght 50 mm
Type of connecting thread 1 Female
Type of connecting thread 2 Male
