U
500 V
I
28 A
P
22 kW
Current type
Three-phase AC
F
50 ? 60 Hz
Accuracy
? 3.5 ?C / ? 6.3 ?F
Digital readings frequency
Actual value on touchscreen
Digital readings power
Actual value on touchscreen
Digital readings temperature
Setpoint and actual value on touchscreen
Digital readings time
Setpoint and actual value on touchscreen
Dimensions display
3,5?
Dimensions of generator [LxWxH] (mm)
600 x 300 x 600
Extra thermocouple input
+
Forced air cooling
+
Heat curve in display
+
Heating log
?
Inductor recognition
+
MF frequency range
10 ? 25 kHz
Network connection
?
Selection operating mode
via touchscreen
Setpoint power
via touchscreen
Setpoint temperature
via touchscreen
Setpoint temperature curve
+
Setpoint timer
via touchscreen
Signal tower
Option
Signaling by ...
End of heating cycle: green continuous light/acoustic signal
Temperature measurement
for type K thermocouple
Temperature sensor
yes, for max 300 ?C / 572 ?F
Trolley
Option
USB connection
?
