PER.GW211SPP17-TTU

Consultar precio

Unidad de muñón para labranza (TTU) con agujero cuadrado y sellado integral

MPN: PER.GW211SPP17-TTU Marca: SKF Categoría: Productos Industriales SKF Subcategoría: Componentes Industriales SKF Familia: Producto Genérico SKF Subfamilia: Componente Genérico SKF
These Tillage Trunnion Units (TTU) with integral sealing are designed mainly for agricultural applications, such as gang disc arrangements for secondary tillage. The square bore enables ease of mounting on mating square shafts. The two trunnions form an axis that allows the shaft to pivot. The integral sealing protects the units from the ingress of mud, water, dust and crop residues, and can avoid the need for relubrication.
Capacidad de carga dinámica básica 43.4 kN
Capacidad de carga estática básica 29.2 kN
Diámetro del agujero 38.887 mm
Lubricante Grasa
Material, rodamiento Acero para rodamientos
Material, soporte Ductile iron
Peso neto del producto 4.55 kg
Sellado Con
Tipo de sellado Sello
Tipo de agujero Cuadrada
Aro de asiento de caucho Sin
Aplicación Para aplicación en discos de grupo
Estándar No estandarizados
