TK 118 V

Consultar precio

Sello de taconita

MPN: TK 118 V Marca: SKF Categoría: Soportes y rodamientos montados Subcategoría: Soportes de rodamientos Familia: Accesorios para soportes Subfamilia: Componente Genérico SKF
These taconite seals consist of two rings (one stationary and one rotating), which form a very narrow labyrinth between the two rings, which prevents ingress of solid and liquid contaminants, even during high-pressure washdowns. The rotating labyrinth ring carries a V-ring seal that seals against the stationary labyrinth ring. The V-ring seal blocks contaminants from entering the bearing housing and aids the purging of contamination and old grease when the seal is relubricated.
Código UNSPSC 31171519.0
Código eClass 23-05-17-90
DIÁMETRO DEL EJE 114.3 mm
Diámetro exterior 136 mm
Material Acero con elementos de caucho de nitrilo
Peso neto del producto 4.25 kg
Tipo de accesorio Sello del soporte
Tipo de sellado Taconita
