TRI-SECTION-PLATE-210

Name: TRI-SECTION-PLATE-210
Brand: Schaeffler
Availability: InStock

Consultar precio

Tri-section extraction plate, Removal tool, mechanical

MPN: TRI-SECTION-PLATE-210 Marca: Schaeffler Categoría: Digital and Service Solutions Subcategoría: Herramientas mecánicas Familia: Bearing Puller Subfamilia: Tri-Section Plates

BETEX Tri-Section-Plate for removing complete bearings or tight fitted inner rings; with good radial and axial access, it offers the possibility of grabbing the inner ring so that the pulling force is not transmitted via moving parts and damage to the bearing is avoided

D 285 mm

G 2 mm

Usability in combination with puller: HP/HSP63, 83

wmax 210 mm

wmin 50 mm

Bmax 280 mm

C 117 mm

E 7/8?-14UNF

F 10 mm

Fz max 75 kN

H 9 mm
