TRI-SECTION-PLATE-495

Name: TRI-SECTION-PLATE-495
Brand: Schaeffler
Availability: InStock

Consultar precio

Tri-section extraction plate, Removal tool, mechanical

MPN: TRI-SECTION-PLATE-495 Marca: Schaeffler Categoría: Digital and Service Solutions Subcategoría: Herramientas mecánicas Familia: Bearing Puller Subfamilia: Tri-Section Plates

BETEX Tri-Section-Plate for removing complete bearings or tight fitted inner rings; with good radial and axial access, it offers the possibility of grabbing the inner ring so that the pulling force is not transmitted via moving parts and damage to the bearing is avoided

D 610 mm

G 2 mm

Usability in combination with puller: HP/HSP/HXP 203, 303

wmax 495 mm

wmin 140 mm

Bmax 660 mm

C 235 mm

E 1??-12UNF

F 20 mm

Fz max 290 kN

H 12 mm
